Inconel 718 is a nickel-based superalloy known for its outstanding strength, corrosion resistance, and ability to retain mechanical properties at elevated temperatures. These characteristics make it indispensable in high-performance industries such as aerospace, automotive, energy, and chemical processing. However, transforming this tough alloy into precision components using metal stamping is no easy feat.In this blog, we will guide you through the full production process of Inconel 718 metal stampings—from initial design and engineering to stamping, heat treatment, quality control, and final delivery. Whether you’re a procurement manager, mechanical engineer, or OEM partner, this deep dive will help you understand what goes into creating reliable stamped parts that can perform under pressure.
Inconel 718 is a precipitation-hardenable alloy composed primarily of nickel, chromium, and iron, along with trace elements like niobium and molybdenum. Its excellent tensile strength, fatigue resistance, and oxidation resistance make it ideal for extreme environments. However, its very properties—high strength, low thermal conductivity, and work-hardening behavior—make traditional stamping processes difficult.Stamping Inconel 718 requires specialized equipment, carefully designed tooling, and temperature control. Without the right approach, the material may crack, gall, or cause rapid tool wear, resulting in unacceptable quality and higher costs.
The process begins with an in-depth understanding of the part’s function, environmental exposure, and stress loads. Engineering teams consider key factors such as corrosion exposure, temperature limits, and fatigue cycles to select the optimal thickness and temper of Inconel 718.
Advanced CAD models are created based on the application needs. Finite Element Analysis (FEA) simulations are often used to predict material behavior under forming pressure, which helps engineers optimize part geometry and tooling before production begins.
Due to the toughness of Inconel 718, custom tooling is essential. Dies are constructed using hardened tool steels or carbide, and coated with anti-galling materials such as titanium aluminum nitride (TiAlN). Tooling must also accommodate thermal expansion during hot or warm forming.
Inconel 718 can be stamped under various temperature conditions depending on part complexity and volume:
Cold stamping is limited to simple geometries with thin sheet stock but can result in cracking or springback if not controlled precisely.
Warm stamping (600–800°C) improves ductility while reducing the risk of tearing and die wear.
Hot stamping (1000°C and above) is ideal for complex or deep-drawn components, allowing maximum formability.
Raw Inconel 718 sheets are cut into blanks using laser or waterjet cutting. Surface preparation is performed to remove oxides or contaminants that could affect the stamping process.
The stamping process is typically carried out using a mechanical or hydraulic press with progressive or transfer dies. Each stage progressively shapes the part, with intermediate lubrication and annealing steps as needed to maintain formability.
After forming, additional operations such as trimming, punching, and piercing are carried out to refine the geometry, add mounting holes, or prepare the component for final assembly.
To relieve stress and enhance mechanical properties, stamped parts are solution annealed at temperatures around 1700–1850°F (925–1010°C). This process dissolves hardening precipitates and homogenizes the microstructure.
A two-step age hardening process follows to precipitate γ' and γ" phases, giving Inconel 718 its remarkable strength. The final hardness and tensile strength can be adjusted depending on application requirements.
Finishing operations such as passivation, shot peening, or electropolishing are applied to improve surface corrosion resistance and fatigue life. For highly precise features, CNC machining may be performed as a secondary process.
Stringent quality control ensures that each part meets dimensional and material requirements. Typical inspections include:
Coordinate Measuring Machine (CMM) checks
Dye penetrant inspection for cracks
X-ray or ultrasonic non-destructive testing (NDT)
Metallographic analysis (grain size, phase distribution)
Manufacturers that supply critical industries are typically certified to standards such as ISO 9001, AS9100 (aerospace), or NADCAP (heat treatment & NDT).
Stamped Inconel 718 components are widely used in demanding applications such as:
Aerospace: Exhaust systems, turbine blades, brackets, and shielding
Automotive: Turbocharger components, EV battery enclosures, heat shields
Power Generation: Nuclear containment parts, gas turbine seals
Oil & Gas: Downhole equipment, valve seals, subsea brackets
In one notable case, an aerospace manufacturer replaced a CNC-machined turbine bracket with a hot-stamped Inconel 718 part, reducing production time by 40% and cost by 20%—all while improving fatigue resistance.
Yes, with the right tooling and thermal management, Inconel 718 can be mass produced via stamping, making it cost-effective compared to full machining.
Absolutely. Using warm or hot stamping techniques and intermediate annealing steps significantly reduces the risk of cracking or tearing.
Lead times vary depending on part complexity and tooling requirements, but once tooling is complete, production can typically begin within 2–4 weeks.
In some cases, yes. While stamping handles the bulk geometry, features like threads, ultra-tight tolerances, or surface finishes may require CNC operations.
When failure isn’t an option, you need more than just a supplier—you need a manufacturing partner with the experience, equipment, and certifications to deliver precision parts on time and on spec.
At DENGWEISTEEL, we specialize in Inconel 718 stamping services for critical industries. From aerospace brackets to nuclear shielding, we’ve helped global clients streamline production and maintain reliability under the harshest conditions.
Contact us today for a custom quote or to discuss your next project.
